Electric Circuits II (EE 20234)

University of Notre Dame


Spring 2022 - Enroll in EE20234 section 01
MWF 11:30 AM - 12:20 PM - DeBartolo Hall 126

Course Vault
Description: This is the second undergraduate course in electric circuits. It focuses on AC circuit analysis, the analysis of a passive circuit's response to time-varying sources, and introduces frequency response concepts used in passive and active filter design. AC circuit analysis is an essential tool for those working with electric power grids. It uses complex-valued phasors to characterize the sinusoidal signals found in power systems. To properly design and interface embedded devices to the outside world, it is essential that the engineer be able to predict how a given circuit might respond to time-varying inputs. The main tool one uses to predict a circuit's dynamic response is the Laplace transform; a mathematical operator that transforms time-domain circuit models (i.e. differential equations) into complex valued algebraic models (i.e. transfer functions). This approach allows one to characterize a circuit's response in terms of its frequency response and provides a widely used conceptual basis for circuit analysis and synthesis.
Topics PART 1 - AC Analysis
  1. Phasors and Complex Arithmetic
  2. Impedance and Mesh/Nodal AC Analysis
  3. Source Transformations and Circuit Reduction
  4. AC Power System Analysis - examples
Topics PART 2 - Laplace Transform Circuit Analysis
  1. Laplace Transforms
  2. Operation Transforms, Solving ODE's, and Inverse Laplace Transforms
  3. Laplace Transform mesh/nodal analysis
  4. Laplace transform Circuit Analysis - reduction methods
  5. Laplace transform circuit analysis - transient analysis
Topics PART 3 - System Concepts for Circuit Applications
  1. Meta-View: Transfer Functions
  2. Frequency Response and Bode Plots
  3. Frequency Selective Filtering
  4. Stability and Regulation
  5. Fourier Series and Comm. Systems
Exam Schedule:
Midterm Exams: 1/31, 3/2, 4/6
Final Exam: TBA
Grading: Homework 30% - Midterm Exams (3) 15% each - Final Exam 25%
Instructor: Michael Lemmon, Dept. of Electrical Engineering, University of Notre Dame, Fitzpatrick 275C, lemmon at nd.edu
Textbook: J.W. Nilsson and S.A. Riedel, Electric Circuits, Pearson, 10th or 11th edition
